Guided Wave Technology's Coupling Matrix Synthesis (CMS) software facilitates synthesis of N+2 coupling matrices for Chebyshev bandpass filtering functions, with arbitrary finite-position transmission zeroes.

The CMS software allows placement of complextransmission zeroes, which opens up for group delay shaping.

• zeroing of very weak couplings in order to see if they can be omitted in a physical filter

• change of coupling signs

• investigation of other N+2 coupling matrices e.g. in the literature

• analysis of where unintended couplings may arise from in a physical filter (often seen as extra notches or asymmetry in measured characteristics).

• sensitivity analysis of critical couplings

Below: Monte-Carlo analysis on coupling coefficients.
Same variation applied on three different topologies

The software gives a fast and accurate overview of

• Insertion loss

• Isolation

• Group delay

• Phase

• Coupling coefficients

• Stored energy per resonator

versus

• Filter order

• Return loss

• Resonator unloaded Q

• Transmission zero positions

• Topology

Stored energy plots for each resonator is 'a must' for power handling analysis

CMS is intended for engineers, system designers, sales people, teachers, students and others who are engaged in design and analysis of microwave filters from both component and system point of views.
The software is intuitive and simple to operate and requires only basic knowledge about filters and filter terms.

The resonance characteristic of a single resonator in CMS is 100% symmetric and couplings are assumed constant versus frequency. The calculated characteristics are therefore most accurate for narrow band filters (< 10 %) with resonating elements which have symmetric characteristics.

Check out accuracy and utility with the following examples:

Triplet dielectric resonator filter

8 pole cross coupled combline filter

Group delay shaping - introduction+advanced

Topology investigation by Monte-Carlo Analysis

Coupling Coefficient Signs - Change of

April 2010

Narrow-band Microwave Bandpass
Filter Design by Coupling Matrix Synthesis

The full MWJ article - original document

Exporting Spice Netlist of CMS filter to circuit simulator

X-couplings in filters - How do they work?

Topology and Power Handling

September 2012

Simplified Power Handling Analysis of
Microwave Filters

The full MWJ article - original document

July 2018

Design of an Ultra-Wideband 'Brick Wall' Filter
